Brand Name : | IEC-LR031.5 volts battery |
Model Number : | Triple A Batteries LR03AAA |
Certification : | CE/REACH/Rohs |
Price : | bargain |
Payment Terms : | T/T |
Supply Ability : | 10000000 per month |
Delivery Time : | 5-10 working days |
Battery type Alkaline battery
Series Dry cell battery
Diameter 9.5-10.5mm
Height 43.3-44.5mm
Data sheet for AAA batteries LR3
Model | LR03 AAA |
Diameter | 9.5-10.5 |
Height | 43.3-44.5 |
Norminal voltage | 1.5 volt |
Test condition/discharge time | 10Ω, 24h/d, 0.9V / 8H |
3.9Ω, 24h/d, 0.9V/ 2.5H | |
Storage time | more than 5 years |
LOGO | OEM |
Package | Welcome OEM customer logo too |
Battery pack | any combinations welcome customized |
Dimensions of Battery ( LR03)
Alkalaine battery LR03 AAA battery packing detail
Type | Blister packing | Shrink packing | ||||||||
Pack | Inner box | Carton | Measurement | G/W | Pack | Inner box | Carton | Measurement | G/W | |
LR03/ AAA/ 1.5v | 4B/card | 30 cards | 240 cards | 395*297*214mm | 13.6 kgs | 4S/shrink | 40 pcs | 1200 pcs | 240*230*161mm | 14.3 kgs |
2S/shrink | 40 pcs | 1200 pcs | 240*230*161mm | 14.3 kgs |
Hot sale Alkaline batteries from Hynna
Alkaline Primary battery
Model | Diameter mm | Height mm | Norminal Voltage V | Test condition | Discharge |
23A | 9.9-10.2 | 28.1-28.7 | 1.5 | 20KΩ, 24h/d, 7.2V | 98h |
27A | 7.65-7.85 | 27.7-28.3 | 1.5 | 20KΩ, 24h/d, 7.2V | 36h |
LR03/AAA/七号 | 9.5-10.5 | 43.3-44.5 | 1.5 | 10Ω, 24h/d, 0.9V | 8h |
3.9Ω, 24h/d, 0.9V | 2.5h | ||||
LR6/AA/五号 | 13.5-14.5 | 49.2-50.5 | 1.5 | 10Ω, 24h/d, 0.9V | 19.1h |
3.9Ω, 24h/d, 0.9V | 6.4h | ||||
LR14/C/二号 | 24.9-26.2 | 48.6-50.0 | 1.5 | 3.9Ω, 24h/d, 0.8V | 20h |
6.8Ω, 1h/d, 0.9V | 39h | ||||
LR20/D/大号 | 32.3-34.2 | 59.5-61.5 | 1.5 | 22Ω, 24h/d, 0.8V | 19h |
3.9Ω, 1h/d, 0.9V | 42h | ||||
6LR61/9V | 26.5*17.5*48.5 | 9 | 180Ω, 24h/d, 4.8V | 800min | |
270Ω, 1h/d, 5.4V | 1150min |
Alkaline Rechargeable battery
Model | Diameter | Height | Norminal Voltage | Test condition | Discharge | Cycle life Times |
HR03/AAA/7号 | 9.5-10.5 | 43.3-44.5 | 1.5 | 100mA, 24h/d, 0.9V | 900mAh | 50-200 times |
300mA, 24h/d, 0.9V | 600mAh | 50-200 times | ||||
HR6/AA/5号 | 13.5-14.5 | 49.2-50.5 | 1.5 | 100mA, 24h/d, 0.9V | 1800mAh | 50-200 times |
300mA, 24h/d, 0.9V | 1500mAh | 50-200 times |
USAGE GUIDE (Please refer to lEC60086.5 for detailed safety and
storage specifications.
(1) insert batteries correctly with regard to the polarities
(“+""-") marked on the battery and theelectrical appliances.
(2) Do not short-circuit, recharge, heat, disassemble the battery,
or dispose of in fire.
(3) Do not mix use old batteries with new ones, or mix use
batteries of different types, chemistries orbrands.
(4)Exhausted batteries should be immediately removed from the
equipment.
(5) Keep the batteries away from small children. Do not let the
child remove/replace batterieswithout monitoring from adults.
(6)Storage temperature: 5°C~30°c, and humidity conditions RH:
40%~90%.
![]() |
