Shenzhen Hynna Battery Co.,Ltd.
1 Years
| Ask Lasest Price | |
| Brand Name : | Batteries D LR20 1.5V Alkaline |
| Model Number : | D Alkaline Batteries 1.5V LR20 MN1300 |
| Certification : | CE/REACH/Rohs |
| Price : | bargain |
| Payment Terms : | T/T |
| Supply Ability : | 10000000 per month |
| Delivery Time : | 5-10 working days |
Primary Alkaline Manganese battery 1.5 V battery LR20 size D batteries with blister card or shrink OEm
LR20 D 1.5v Non-Rechargeable Battery (Pack of 2)
Warranty 1 Year Mfg
Highlights Alkaline Battery
Capacity: 18000 mAh
D LR20 1.5V alkaline battery
Designed to provide reliable and lasting performance for both high
and low drain devices
MN1300-R4 D-cell 1.5V Alkaline Button Top Batteries Alkaline D
Cells
Alkaline CopperTop are new and improved to meet the growing needs
of consumers.
The technology of the CopperTop battery has been constantly upgraded to provide advanced performance in popular battery powered devices.
D batteries are recognized worldwide as the industry leader for quality and performance.
The Alkaline cell is best suited when you need reliable, long
lasting life from your everyday devices!
Notable Features of D battery 1.5 volt cell
» LR20/D batteries in a TWO-piece package
» Also known as: 13A, 13D, 813, AL-D, AM1, D, E95, EN95, KD, LR20,
LR20XWA, MN1300, MX1300, PC1300, R20
» 1.5V alkaline cells compatible with flashlights, toys, and other
electronics
This is a primary alkaline battery and is non-rechargeable.
Placing any primary battery — including a MN1300/D battery — into a battery charger will cause irreparable damage to both the battery and charge station.
LR20 D size battery Alkaline 1.5V cell specification
LR20 batteries is a disposable battery that with 1.5V voltage and 18000mah capacity ,under testing condition 10mA, 24h/d, 20°c,e.v.=0.8V
Type D battery 1.5 volt part number Lr20 battery material Alkaline cell with Diameter 32.3~34.2mm and Height 59.5~61.5 mm
Alkaline battery D weight arround 141 g
| Type | Diameter mm | Height mm | Weight kg | Capacity mah | Testing condition |
| LR20/ D / 1.5v | 32.3~34.2 | 59.5~61.5 | 0.141 | 18000 | 10mA, 24h/d, 20°c,e.v.=0.8V |
Standard packages for D type battery
1.5 Volt batteries in size D lR20 alkaliine batteries welcome any Customized
can be come with blister card 2pcs per card or 2pcs shrink
Blistcard OEM LOGO or BOx OEM / odm very welcome
We are the factory then provide any customization service for you
| Blister packing | Shrink packing | ||||||||
| Pack | Inner box | Carton | Measurement | G/W | Pack | Inner box | Carton | Measurement | G/W |
| 2B/card | 12 cards | 48cards | 325*203*243mm | 14.8 kgs | 2S/shrink | 12 pcs | 96 pcs | 297*231*158 mm | 14.2 kgs |
USAGE GUIDE (Please refer to lEC60086.5 for detailed safety and
storage specifications.
(1) insert batteries correctly with regard to the polarities
(“+""-") marked on the battery and theelectrical appliances.
(2) Do not short-circuit, recharge, heat, disassemble the battery,
or dispose of in fire.
(3) Do not mix use old batteries with new ones, or mix use
batteries of different types, chemistries orbrands.
(4)Exhausted batteries should be immediately removed from the
equipment.
(5) Keep the batteries away from small children. Do not let the
child remove/replace batterieswithout monitoring from adults.
(6)Storage temperature: 5°C~30°c, and humidity conditions RH:
40%~90%.
Hot sale Alkaline batteries from Hynna
Primary Alkaline battery cell
| Model | Diameter mm | Height mm | Norminal Voltage V | Test condition | Discharge |
| 23A | 9.9-10.2 | 28.1-28.7 | 1.5 | 20KΩ, 24h/d, 7.2V | 98h |
| 27A | 7.65-7.85 | 27.7-28.3 | 1.5 | 20KΩ, 24h/d, 7.2V | 36h |
| LR03/AAA/七号 | 9.5-10.5 | 43.3-44.5 | 1.5 | 10Ω, 24h/d, 0.9V | 8h |
| 3.9Ω, 24h/d, 0.9V | 2.5h | ||||
| LR6/AA/五号 | 13.5-14.5 | 49.2-50.5 | 1.5 | 10Ω, 24h/d, 0.9V | 19.1h |
| 3.9Ω, 24h/d, 0.9V | 6.4h | ||||
| LR14/C/二号 | 24.9-26.2 | 48.6-50.0 | 1.5 | 3.9Ω, 24h/d, 0.8V | 20h |
| 6.8Ω, 1h/d, 0.9V | 39h | ||||
| LR20/D/大号 | 32.3-34.2 | 59.5-61.5 | 1.5 | 22Ω, 24h/d, 0.8V | 19h |
| 3.9Ω, 1h/d, 0.9V | 42h | ||||
| 6LR61/9V | 26.5*17.5*48.5 | 9 | 180Ω, 24h/d, 4.8V | 800min | |
| 270Ω, 1h/d, 5.4V | 1150min | ||||
Alkaline Rechargeable battery
| Model | Diameter | Height | Norminal Voltage | Test condition | Discharge | Cycle life Times |
| HR03/AAA/7号 | 9.5-10.5 | 43.3-44.5 | 1.5 | 100mA, 24h/d, 0.9V | 900mAh | 50-200 times |
| 300mA, 24h/d, 0.9V | 600mAh | 50-200 times | ||||
| HR6/AA/5号 | 13.5-14.5 | 49.2-50.5 | 1.5 | 100mA, 24h/d, 0.9V | 1800mAh | 50-200 times |
| 300mA, 24h/d, 0.9V | 1500mAh | 50-200 times |
|
|
